Page 2
S
PECIFICATIONS
NOMINAL
MODEL
CURRENT
OPTIONS
LPU
50
M - Outdoor enclosure with
150
clear door (NEMA 4X)
200
P - Positive ground
Specifications and product availability subject to change without notice.
PART NUMBERING KEY
EXAMPLE:
Model
Nominal Current
Options
LPU - 50 - M
PARAMETERS
UNITS
VALUE
Nominal Voltage
(Volts)
12-48
Array Voc., Max.
(Volts)
95
Array Current, Continuous / Channel
(Amps)
50
Array Current, Max / Channel (60 seconds)
(Amps)
65
Primary Stage
Single Impulse Discharge Current,
8/20
µ
sec waveform, Max.
(Amps)
20,000
Impulse Life - 1000A,
10/1000
µ
sec waveform, Min.
(Surges)
400
Typ.
(Surges)
600
DC Breakdown Voltage
Line to Ground
(Volts)
150-300
Impulse Breakdown Voltage
Line to Ground
@ 100 V /
µ
sec, Typ.
(Volts)
500
Max.
(Volts)
750
@ 10 KV /
µ
sec, Typ.
(Volts)
750
Max.
(Volts)
1000
DC Holdover @ 200mA, Min.
(Volts)
150
Secondary Stage
Peak Surge Capacity
8/20
µ
sec, Max.
(Amps)
1500
Peak Voltage Clamping
@1mA, Min.
(Volts)
85
Max.
(Volts)
115
Response Time, Typ.
(Nanosec.)
50
