Quick Start | 5
•
VOICE (C):
a gradual timbre adjustment affecting the overall character
of each distortion
•
TONE (D):
cuts or boosts the selected TONE SHAPE (TREBLE, MID,
and BASS).
•
OUTPUT (E):
adjusts the output level of the effect.
•
NOISE GATE BUTTON (F):
selects the noise gate threshold level. Also
selects the External Control mode.
•
TONE SHAPE BUTTON (G):
selects which frequency range will be
adjusted by the TONE knob.
•
FOOTSWITCHES (H):
enable/disable presets. Press and hold to save
an edited preset.
1
2
LOW
(EXP)
MED
(MIDI)
HIGH
(HH)
TONE
SHAPE
NOISE
GATE
DRIVE
VOICE
OUTPUT
TREBLE
MID
BASS
TONE
BENDER
SMOOTH
TUBE
POWER
STAGE
CRUNCH
TUBE
TS9000
BIG PI
EL
RATON
FUZZ
FAÇADE
METAL
OCTAVE FUZZ
TUBE DRIVE
GATED
FUZZ
CUT
BOOST
(HOLD)
FLAT
G
E
A
C
B
F
H
H
D
