DIMENSIONS
ORDERING INFORM ATION
SAMPLE NUMBER: PSL-175-MH-MT
Product Family
PSL=Parking
Structure
Luminaire
PSL
Lamp Wattage
70=70W
85=85W
1
100=100W
150=150W
175=175W
200=200W
2
Lamp Type
MH=Metal Halide
MP=Pulse Start
Metal Halide 2
HPS=High Pressure
Sodium
QL=Electrodless
Fluorescent 1
Voltage
120
208
240
277
480
MT=Multi-Tap
wired 277V 3
TT=Triple-Tap
wired 347V 4
DT=Dual-Tap
wired 347V 5
NOTE: 1 85W QL Electrodless Fluorescent only. 120 or 240V only.
2 200W only.
3 Multi-Tap 120/208/240/277V, wired 208 and 240V.
4 Triple-Tap 120/277/347V, wired 120V, 277V, 347V.
5 Dual-Tap 120/277V, wired 120 and 277V.
6 When specifying F & FF option with the TT or MT Ballast type specify which voltage to be fused. PSL-175-MH-MT-F1-277.
7 Maximum use of (2) GG60’s or (2) LTS accessories when used with wattages in excess of 100W.
8 Other finish colors available. Consult McGraw-Edison Architectural Colors brochure.
Options (add as suffix)
F=Single Fuse (120, 277, 347V)
6
FF=Double Fuse (208, 240, 480V) 6
Q=Quartz Restrike (Hot Restrike Only)
EM=Emergency Separate Circuit
TR=Tamper Proof
L=Lamp Included
CT=Conduit Taps
PL=Polycarbonate Lens
7
(UV Inhibitor Applied)
Optional Colors (add as suffix) 8
AP=Grey
BZ=Bronze
WH=Architectural White
BK=Black
Accessories (order separately)
BGL=Bird Guard
GG60=Glare Guard
TM=Trunnion Mount Kit
LTS=Light Trespass Shield
Catalog Lamp Lamp Ballast Net Wt
Number Wattage Type/Base Type (lbs)
PSL-100-MH-120 100 MH 120 31
PSL-100-HPS-120 100 HPS 120 31
PSL-150-HPS-MT 150 HPS MT 34
PSL-175-MP-MT 175 MP MT 34
ordering information
14 3/4" [375mm]
11 7/8"
[302mm]
OPTIONS
Q L 8 5 I N D U C T I O N
E L E C T R O D L E S S F L U O R E S C E N T
G G 6 0
G L A R E G U A R D
L T S
L I G H T T R E S P A S S S H I E L D
photometric performance
40' Spacing/
30' Separation
20' Spacing
20' Spacing
Reflectance: 20% Floor, 0% Walls, 20% Ceiling
Single Row
Single Row
with GG60
Double Row
Alternating
Double Row
Combination
2/1 Row
Layout
60' Wide Bays,
8'-10' Mounting Height
175W Metal Halide
14,400 Lumens
175W Metal Halide
14,400 Lumens
175W Metal Halide
14,400 Lumens
100W Metal Halide
8,500 Lumens
100W Metal Halide
8,500 Lumens
5.1
5.2
2.8
2.8
2.8
2.0
2.1
1.1
1.1
1.2
9.8
9.8
7.2
6.9
7.2
2.8
Lamp Wattage
Horizontal Vertical
Ave. fc Min. fc Max./Min. Min. fc @ 5'
3.0
1.0
0.9
0.6
Spacing
20' Spacing/
30' Separation
30' Spacing/
30' Separation
Double Row
With GG60 85W QL
6,000 Lumens
2.2 1.0 4.1 1.1
40' Spacing/
30' Separation
APPLIC ATION DATA
P S L - 1 7 5 - M H - M T / 175-Watt Metal Halide / 14,400-Lumen Clear Lamp
Side Throw with LTS
30
°
60 °
90
°
Driver Aisle with GG60
30
°
60
°
90 °
Maximum CD Throw Driving Aisle
30 °
60
°
2000
4000
90
°
IES
File#
H39164
IES
File#
H39165
IES
File#
H39166
P S L - 8 5 - Q L / 85-Watt QL Induction / 6,000-Lumen Diffuse Lamp
Driver Aisle with GG60
30 °
60 °
90
°
Maximum CD Throw Driving Aisle
30
°
60 °
570
90 °
285
IES
File#
H39164
IES
File#
H39165
PHOTOMETRICS
