Page 9
SOLBERG
B. Large CSL: Loosen wing nut or hex head on T-bolts.
C. CSS: Twist upper housing to release.
D. VS/VL: Remove V-clamp by loosening Hex Nut or T-bolt and releasing.
E. Lift off canister top.
3. Removing element for service/maintenance.
A. Remove retaining hex head/wing-nut and washer carefully, and then
remove element. Some elements will have a top plate that should also be
removed.
B. Clean sealing surfaces of housing, top & base plates, and element
endcaps so that they are free of dirt or any other particulate.
*WARNING*
Failure to comply with these instructions
may result in system or pump contamination.
4. Securing Element.
A. Place new or cleaned element evenly on base plate. Be sure element
seats properly on base and there is no dirt or particulate present on
sealing surfaces.
B. Place top plate (if necessary) on element by centering on tap bolt.
C. Secure washer and wing nut to end cap (or top plate) and tap bolt.
Element must be tightly secured. Note: DO NOT over tighten!
*WARNING*
Defective installation may cause system or
pump contamination. Use only genuine
Solberg replacement parts.
5. Securing canister top to canister base.
A. Make sure all surfaces are free from dust and other particulate.
