Sigtronics 900118 User Manual
Page 4
Vertex Standard
• VX-2000
• VX-2100
• VX-2200
• VX-2500
• VX-3000
• VX-3200
• VX-4104
• VX-4107
• VX-4204
• VX-4207
• VX-4500
• VX-4600
• VX-7100
• VX-7200
Function
8 Pin
Sigtronics Wire Color
MIC LO
D
Black
MIC HI
E
Brown
PTT HI
F
White
PTT LO
D
White
Sigtronics Universal Mobile Radio Microphone Interface “Y” Adapter 8 Pin
Tait
• TM8110
• TM8115
• TM8235
• TM8250
• TM8254
• TM8255
• TM8260
• TM9135
• TM9155
Function
8 Pin
Sigtronics Wire Color
PTT HI
D
White
MIC HI
E
Brown
MIC LO
F
Black
PTT LO
F
White
Standard (Vertex / Yaesu)
• GX4800
• GX5800
Function
8 Pin
Sigtronics Wire Color
MIC LO
C
Black
PTT LO
C
White
MIC HI
D
Brown
PTT HI
E
White
Tekk
• MT-800
Function
8 Pin
Sigtronics Wire Color
MIC LO
B
Black
PTT LO
B
White
MIC HI
E
Brown
PTT HI
F
White
SEA
• Sideband
• ESP504
• ESP520
Function
8 Pin
Sigtronics Wire Color
PTT HI
C
White
MIC HI
F
Brown
MIC LO
G
Black
PTT LO
G
White
RELM
• RMU800A
• RMU8125
• RMU8145
• RMU8150
• RMV800A
• RMV8125
• RMV8145
• RMV8150
Function
8 Pin
Sigtronics Wire Color
MIC HI
C
Brown
MIC LO
D
Black
PTT HI
E
White
PTT LO
F
White
RELM
• RMU25
• RMU45
• RMV25
• RMV50
Function
8 Pin
Sigtronics Wire Color
MIC LO
D
Black
PTT LO
D
White
MIC HI
E
Brown
PTT HI
F
White
Motorola
• MCX1000
Function
8 Pin
Sigtronics Wire Color
PTT LO
B
White
MIC HI
C
Brown
PTT HI
E
White
MIC LO
F
Black
Motorola
• MICOM-3R
• MICOM-3T
Function
8 Pin
Sigtronics Wire Color
MIC LO
D
Black
PTT LO
D
White
MIC HI
E
Brown
PTT HI
F
White
