Sigtronics 900118 User Manual
Page 3
Sigtronics Universal Mobile Radio Microphone Interface “Y” Adapter 8 Pin
ICOM
• IC-A110
• IC- F110 / F111 / F121 / F121S / F210 / F211 / F221 / F221S / F320 / F320S
/ F420 / F520 / F521 / F620 / F621 / F1020 / F1721 / F1721D / F1821 /
F1821D / F2020 / F2721 / F2721D / F2821 / F2821D / F5011 / F5021 /
F5121D / F5061 / F6011 / F6021 / F6061 / F6121D / F9511HT / F9511S /
F9511T
• IC-V8000
• IC-207H / 706 / 2000 / 2000H / 2200H / 2300H / 2350H / 2820H / 7000
Function
8 Pin
Sigtronics Wire Color
PTT HI
D
White
MIC LO
E
Black
MIC HI
F
Brown
PTT LO
G
White
Kenwood
• NX-700 / 700H / 800 / 800H / 900
/ 901 / 920 / 920G
• TK-750 / 760G / 760HG / 762G
/ 762HG / 780 / 850 / 860G / 860HG
/ 862G / 862HG / 863G / 880 / 885
/ 980 / 981 / 5720 / 5820 / 6110
/ 7102H / 7150 / 7160 / 7180 / 7302
/ 7360HV / 8102H / 8150 / 8160
/ 8180 / 8302 / 8360HU
• TK-7100 and TK8100
( International Models, not US )
• TKR-750 and TKR-850
• TM-G707A / G707E / V7A / V7E
/ 261 / 271 / 461 / 471 / 642A
/ 742A / 742E / 942A
Function
8 Pin
Sigtronics Wire Color
MIC HI
C
Brown
MIC LO
D
Black
PTT HI
E
White
PTT LO
F
White
Midland
• Syntech Bantam Series
• Titan Series
Function
8 Pin
Sigtronics Wire Color
MIC LO
F
Black
PTT LO
F
White
PTT HI
G
White
MIC HI
H
Brown
Motorola
• CM 200 and CM 300
• GM 140 / 160 / 300 / 350 / 600 /
900 / 950 / 1100 / 1200 / 2000
• GTX
• HT-100 MVA Convertacom
• LCS2000
• M10, M100, M120, M130, M208,
M214, M216 Radius Series
• Maxtrac 100, 300, 800
• MC900 and MC2100
• MCS-2000
• MCX600, MCX1200, MCX2000
• MTS-2000 MTVA Convertacom
• PM400
• SM50 and SM120
• XTVA for XTS Portables
(convertacom type box)
Function
8 Pin
Sigtronics Wire Color
PTT HI
C
White
MIC HI
D
Brown
MIC LO
E
Black
PTT LO
E
White
Klein Electronics
• Blackbox-M-U
• Blackbox-M-V
• Blackbox-M-V-S
Function
8 Pin
Sigtronics Wire Color
MIC HI
F
Brown
MIC LO
E
Black
PTT HI
G
White
PTT LO
H
White
Maxon
• SM-2102
• SM-2402
• SM-2541
• SM-2544
• SM-5102
• SM-5402
• SM-6150
• SM-6450
Function
8 Pin
Sigtronics Wire Color
MIC LO
B
Black
PTT LO
B
White
MIC HI
E
Brown
PTT HI
F
White
Midland
• ML Series (Legacy)
• MO Series (Olympian)
Function
8 Pin
Sigtronics Wire Color
MIC LO
B
Black
PTT LO
B
White
MIC HI
E
Brown
PTT HI
F
White
Midland
• STM-1050B
• STM-1055B
• STM-4040A
• STM-4045A
Function
8 Pin
Sigtronics Wire Color
MIC LO
A
Black
PTT LO
A
White
PTT HI
G
White
MIC HI
H
Brown
