Contents
Instruction manual
1. General instructions 2
2. Safety regulations 3
3. Product description 4
3.1. General description of the firearm 4
3.2. Main features 4
3.3. Various models 6
3.4. Options 6
3.5. Technical data 7
3.6. Scope of supply 8
4. Transporting the firearm 8
5. Handling the firearm 9
5.1. General remarks 9
5.2. Initial preparation 9
5.3. Ammunition 9
5.4. Loading the magazine 9
5.5. Loading the firearm (ready to fire) 9
5.6. Discharging a shot 10
5.7. Reloading during shooting 10
5.8. Unloading the firearm 11
5.8.1. Unloading the firearm, magazine not emptied 11
5.8.2. Unloading the firearm, magazine emptied,
slide open 11
6. Adjusting Sight 12
6.1. Correcting the sights 12
7. Maintaining the firearm 13
7.1. Stripping the firearm 13
7.2. Removing the front sight base 13
7.3. Maintenance 13
8. Description of the functions 14
9. Service and repairs 14
9.1. Safekeeping and storage of firearm 14
9.2. Shipping the firearm 14
10. Accessories 15
11. Disposal 15
12. Spare parts 16
12. Spare parts
Required information for or-
dering replacement parts: – Firearm model
– Firearm number
– Caliber – Item number
– Name/designation
of individual part
Item Designation Item Designation Item Designation
Slide
1
Locking piece, LS
1a Slide
2
Barrel, 150 mm
2a Barrel, 150 mm with rifling
2b Barrel, 120 mm
3
Recoil spring
4 Firing pin
5 Firing pin spring
6 Extractor
7 Extractor spring
8 Firing pin plate
9 Extractor pin
Sights (specify size!)
10 Front sight for microme-
ter sights
10a Front sight for normal
sights
10b Front sight for contrast
sights
Sights
11 Normal sights
11a Contrast sights
Mikrometer sights
12 Rear sight base
13 Rear sight
14 Windage correction screw
15 Side spring
16 Sight pin
17 Height adjustment screw
18 Height spring
19 Steel bullet
20 Sight blade
Front sight base
21 2 round nuts
22 2 spacer washers
23 Front sight base
24 Front sight wedge
24a Cover for front sight slot
10 Front sight for micrometer
sights
Grip
25 Grip for magazine catch,
side
25a Grip for magazine catch,
below
26 Trigger
27 Trigger guide
28 Trigger guide pin
29 Trigger spring
30 Trigger pin
31 Slide stop spring
32 Slide stop
33 Safety lever
34 Magazine catch, side
35 Magazine catch spring
36 Magazine catch stop
37 Magazine catch stop
spring
38 Grip plate left for
magazine catch, side
38a Grip plate left for
magazine catch, below
39 Grip plate, right
40 Grip plate screw
41 Washer
42 Grip plate nut
43 Grip plate filler
44 Magazine catch pin
45 Locking screw for action
housing
46 Threaded pin for trigger
stop
47 Safety pin for trigger stop
Action
48 Action housing
49 Trigger bar
50 Hammer
51 Pressure lever
52 Pressure lever pin
53 Trigger bar pin
54 Hammer pin
55 Mainspring pin
56 Trigger bar spring
57 Mainspring bar
58 Mainspring
59 Mainspring head
60 Lock nut
Magazine safety
(for magazine catch only,
below)
61 Magazine safety
62 Magazine safety screw
63 Magazine catch, below
Magazine
64 Box magazine for magazi-
ne catch, side
64a Box magazine for magazi-
ne catch, below
65 Magazine floorplate for 64
65a Magazine floorplate
for 64 a
66 Feeder
67 Magazine spring
68 Magazine floorplate insert
16
12-2004
Subject to technical modifications.
Instruction manual -GB- 34 210 006
