GRAPHICS SYMBOLS

Your oven is provided with a display of graphic symbols to help in identifying the use and
function of the available adjustable components.

2.1

Indicates that you should consult your operation manual for further description
and discussion of a control or user item.

2.2

Indicates "AC Power On".

2.3

Indicates "Adjustable Temperature".

2.4

Indicates "Manual Adjustment".

2.5

Indicates "Heating".

2.6

Indicates "Earth Ground"



2.7

Indicates

“Potential Shock Hazard” behind partition

2.8

Indicates “Unit should be recycled” (Not disposed of in land-fill)

Section

2
