2.2 General ECUsim Commands
SF on|off
Turn “Fault” mode on or off. Fault mode is off by
default.
SOMM on|off
Turn OBD bus monitoring on or off. OBD monitoring is
on by default.
SOMMT on|off
Turn timestamp printing on or off. Timestamps are on
by default.
SOMT header, data
Transmit OBD message. The message will be sent over
the active protocol set by the SP command.
SI
Print device information.
SP protocol_number
Set active OBD protocol. Note that ECUs must be set
to the same OBD protocol as the simulator to be able to
send and receive messages.
Table 6: OBD Protocol Presets
Protocol # Protocol
0 none
1 J1850 PWM
2 J1850 VPW
Protocol # Protocol
3 ISO 9141-2
4 ISO 14230-4
1
5 ISO 15765-4
2
21 ISO 9141-2 no init
23 ISO 14230-4 no init
24 ISO 14230-4 5-baud init
25 ISO 14230-4 fast init
33 ISO 15765-4 11/500
34 ISO 15765-4 29/500
35 ISO 15765-4 11/250
36 ISO 15765-4 29/250
1 The 5BAUD/FAST switch determines the type of initialization (5 baud
or fast).
2 Baud rate and CAN ID type are controlled by the 250K/500K and 11/29
BIT switches.
SPBR baud_rate
Set active OBD protocol. Note that ECUs must be set
to the same OBD protocol as the simulator to be able to
send and receive messages.
SPI
Print current OBD protocol settings.
SR
Reset the PIM. This command is equivalent to power
cycling the simulator. It is useful for setting the PIM back
to its “power on” state.
2.3 DTC Commands
DAD ecu_id, fault_set
Delete all DTCs for the specified ECU and fault set.
DPA ecu_id, fault_set, dtc
Add pending DTC to the specified ECU and fault set.
DPDA ecu_id, fault_set
Delete all pending DTCs for the specified ECU and fault
set.
DRA ecu_id, fault_set, dtc
Add permanent DTC to the specified ECU and fault set.
DRDA ecu_id, fault_set
Delete all permanent DTCs for the specified ECU and
fault set.
DSA ecu_id, dtc,fault_set
Add stored DTC to the specified ECU and fault set.
DSDA ecu_id, fault_set
Delete all stored DTCs for the specified ECU and fault
set.
