NOTE: In the off positions the “Hot” handle lever (left) should be in the
“9 o’clock” position, and the “Cold” handle lever (right) should be in
the “3 o’clock” position. In the on positions the levers should both turn
towards you, not away from you.
Fit the handle down onto the installed valve body making sure that the
handle levers are in a parallel line with the spout.
Turn the trim body clockwise onto the valve body until tightened down
securely.
H a n d l e Tr i m
Handle Trim Installation
9555KL, KR, KT _ _
