Chrysler 2004 PT Cruiser - Manual (Page 287)

LIGHTS BULBS — Outside Bulb No.
Low Beam Headlight . . . . . . . . . . . . . . . . . . . 9006XS
High Beam Headlight . . . . . . . . . . . . . . . . . . . 9005XS
Front Park/Turn Signal/Side Marker Light . 4157NAKX
Front Fog Light . . . . . . . . . . . . . . . . . . . . . . . . . 9006
Center High Mounted Stop Light
(CHMSL) . . . . . . . . . . . . . . . . . . . . . . . . . 921–W16W
Rear Tail/Stop/Turn Signal Light . . . . . . 3157–P27/7W
Backup Light. . . . . . . . . . . . . . . . . . . . . 3157-P27/7W
License Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
BULB REPLACEMENT
Headlight Bulb Replacement
CAUTION!
Do not touch the new headlight bulb with your
fingers. Oil contamination will severely shorten
bulb life.
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Disconnect the electrical connector.
3. Rotate the socket to the left one quarter turn and
replace the bulb.
MAINTAINING YOUR VEHICLE 287
7
