Dual Zone Climate Control
AiR RECiRCULATiON
• Use recirculation for maximum A/C operation.
• For window defogging, turn recirculation off.
• Recirculation is not allowed in defrost or defrost/floor
(mix) modes.
Driver PoWer Seat aDjuStment
• The seat switch, located on the outboard side of the seat,
controls forward/back, up/down, and tilt adjustment.
DRivER MANUAL RECLiNE ADjUsTMENT
• Lift the rear lever, located on the
outboard side of the seat, lean
back and release at the
desired position.
LUMbAR ADjUsTMENT
• Rotate the dial located on the outboard
side of the seatback to adjust lumbar
(lower back) support.
Slide Driver
or Passenger
temp. Control
rotate
Blower Control
rotate
mode Control
Push
a/C
Button
Push
recirc.
Button
Push rear
Window
Defroster
Button
Power seat
switch
Recline
Lever
Lumbar
Dial
