Clarke ® B EXT ® -100, 100H 150H, 300HV Operator's Manual Page 41
Clarke ® B EXT ® -300HV, 120V
Parts List 3/06
Ref # Part No. Description Qty
1 59721A Drain Gate (see misc) 1
1A 53606A Spout, Drain Gate 1
2 962929 Screw, 10-32 x 3 /
8
, SS 4
3 52636A Latch 2
4 837304 O-Ring (small) 3
4A
4B
920797 Drain Valve 2
5 30322A Tank, Recovery 1
*6 690212 Adaptor
*7 692701 PVC Elbow, 1½"
8 55674A Lid & Ring, 6" 1
8A 692409 Chain Assemly, 8" 1
8B 34288A Gasket** 1
9 85613A Screw, 8-32 x 7 /
8
"
9A 81109A Nut, 8/32, SS Nylock
10
11
52806A Vacuum Mainfold, Incl. Ball & Cage 1
(includes 10, 10A, 11, 12 and 13)
12
13
14
15
872010 Hose Clamp 2
16 52665A Hose, Rubber
17 52365A Hose Clamp
18 Heat Exchanger Mount 1
19 52566A Heat Exchanger, Complete 1
19A 52834A Thermostat, Heat Switch (see misc) 1
20
21
61350A Hose, 26", High Pressure ¼ I.D. 1
22 52988A Quick Disconnect, Open 1 /
8
", PT 2
23 52989A Quick Disconnect, Male, 1 /
8
" PT 2
24 851144 Bushing Brass, ¼ MPT x 1 /
8
FPT 1
24A 52991A Coupling
25 30323A Hose, Braided, SS 1
26 52992A Washer, Brass
26A 52993A Washer, Fiber
27
28
52995A Bushing, Fiber 1
29
30
Lock Nut, 5 /
16
"
31 Washer, 5 /
16
"
32 Screw, 10-32 x 5 /
8
", SS
33 Nut, 5 /
16
"
34 Washer, 5 /
16
"
35 Bolt, 5 /
16
x 4"
36 52997A PVC Sleeve, 3"
37 52998A PVC Elbow, 90°, 1½", Slip
38 61351A Mount Plate 1
39 52835A Gasket (Vacuum Motor) 1
40 52836A Vacuum Motor (120V) 1
41
42
43
44
46
PVC Reducer
47 Lock Nut
49 40637A Power Cord, 12/3, 25 ft. 2
50
51
52676A Cord Retainer, Water Tight 2
52
53
Ref # Part No. Description Qty
54
55
56
40661A Dual Cord Sensor, Circuit Board 1
57 52664A Mount, Dual Cord Sensor 1
58 52471A Wheel, 10" 2
59 920346 Axle Cap 2
61 61339A Hinge Rod, ¼ x 3½", SS 2
62 52679A Cord Wrap 2
63 170915 Screw, 1/40-20 x 1", SS 2
63A 87026A Washer, ¼, SS 2
64 61338A Axle, 18" 1
65 52673A Louver, 3" 1
66 30635A Gasket, Base
67 40750A Housing, Lower
68 52470A Castor, 4" x 1" 1
69 Bolt, ¼-20 x 3 /
4
" 2
70 52840A Quick Disconnect, Male ¼" PT
70A 61314A Priming Hose 1
70B 52565A Quick Disconnect, Female ¼ PT 1
71 52674A Latch Strike 2
72 52671A Handle, Lifting 1
73 962098 Screw, Flathead 4
75 30338A Tank, Solution 1
76 52841A Filter, Pump Inlet 1
76A 52677A Adapter, Inlet Screen
77 53558A Lid, Solution Tank 1
78 52842A Switch, Pump & Vacuum 3
79 52843A Switch, Heat 1
80 52678A Panel, Control 1
81 52668A Green Light 2
82 Screw, #4 x 3 /
8
SS
84 53639A Elbow 90°, ¼ PT
85 52171A Hose Barb, ¼ PT x ½" Hose
86 50248A Hose Clamp 8
87 Hose, Pump Inlet, ½" x 14"
88 Pump, No Fittings (see misc.)
89 170066 "T" Brass, ¼ PT
90 170086 Nipple, SS, ¼ PT
91 170040 Elbow Brass, ¼ MPT x ¼ FPT
92 Quick Disconnect, Male ¼ PT
93
94
95
696801 Plug, Brass
96 697501 Reducing Nipple, ¼ MPT x 1 /
8
MPT
97 170030 Hose Barb, Brass ¼ PT x 3 /
8
Hose
98 53173A Bypass Valve (see misc.)
99 53174A Hose, 3 /
8
" x 8"
100 690209 Hose Barb, Brass 1 /
8
PT x 3 /
8
Hose
101 52844A Solenoid (120V), NC 1
102 53175A Hose, Pump Bypass, 3 /
8
" x 14"
103 52837A Motor, for Pump (AC, 120V) 1
104 693406 Gasket, Swivel 1
Part # Miscellaneous Assemblies/ Parts
52848A Bypass Rebuild Kit
52846A Valve/O-Ring Kit
52849A Plunger & Seals Kit
53389A Pump Complete (no motor or solenoid)
Pump Complete with Solenoid
Pump & Motor Complete with Solenoid
52845A Bearing/Cam Asm. (for pump)
Drain Gate Complete w/ O-Rings, Nut & Spout
52847A Heat Repair Kit w/Thermostat & Cutout Asm.
Label, Clarke
*
* Items 6, 7 & 104 must be ordered as a set when replacing any original
#6 Adapter and: 3 - 85522A Screws, 1 - 962109 Screw, 1 - 920296 Nut.
** Item 8B must be used with any lid replacement.
