PS Engineering
PRD60 Remote DRAWS Unit
Installation and Operator’s Manual
200-160-0200 Page 1-2 Rev 3, Sept. 2012
This device must accept any interference received, including interference that may cause
undesired operation.
1.5 SPECIFICATIONS
Specifications
ENVIRONMENTAL CONDITIONS:
Temperature Range:
Operating:
Storage:
-15º C to 55º C
-40º C to 85º C
Altitude: Up to 50,000 feet in an unpressurized area of
the aircraft.
DIMENSIONS: Height: 1.25 in. Length: 5.5 in
Width: 4.0 in . (w/ mounting flanges)
WEIGHT (With Connector): 8.5 Oz. (0.34 kg)
POWER REQUIREMENTS
Voltage: 11 to 33 VDC
Maximum Current: 750 mA (Externally protected by a 1 Amp
circuit breaker.)
Audio Specifications
Audio selector panel input impedance: 510 
Input Isolation: -60 dB (min.)
Unswitched Audio: 4 inputs
Headphone Impedance: 150 - 1000 
Headphone Output: 38 mW into headset, no clipping into 150
Distortion: <1% THD @ 38 mW into 150
Audio Freq. Response, 3 dB: 300 Hz - 6000 Hz
1.6 EQUIPMENT SUPPLIED
1 ea. of the following units:
Model Part Number
PRD60 050-160- ( )
