PS Engineering DRAWS - Manual (Page 13)

PS Engineering
PRD60 Remote DRAWS Unit
Installation and Operator’s Manual
200-160-0200 Appendix B Rev 3, Sept. 2012
1A
11-33 VDC
25
13
PRD60 Sub-D DB-25 Male
14
Power In
Ground
Audio Output Hi
16
Aux 1 Input Hi 4
23
11
9
10
21
8
Annunciate 1
Annunciate 2
Annunciate 3
Annunciate 4
Annunciate 5
Annunciate 6
T
o
U
n
s
w
itc
h
e
d
A
u
d
io
S
o
u
rc
e
s
NOTES: 1. All wire must conform to MIL-22759
or 27500. Minumum 24 gage shielded wire.
2. Use 2--conductor with shield
as indicated.
4. Connect shields at one end only
5. No connection Pins 5, 6, 7, 17, 19, 20, 22.
6. See section 2.4 for details of inputs and outputs.
REV
DATE: SHEET 1 OF 1
TITLE:
DOCUMENT NUMBER: SIZE
PRD60 WIRING DIAGRAM (Generic)
120-161-0000 2
12/07/01
9800 MARTEL ROAD, LENOIR CITY TN 37772
Aux 2 Input Hi
Aux 3 Input Hi Aux 3
Audio Output
Aux 2
Audio Output
Aux 1
Audio Output
3
Acknowledge
24
Annunciator
Acknowledge
18 Audio Lo
Aux 4 Input Hi Aux 4
Audio Output 15
Audio Panel
Unsw. Input
Rev 2 9/11/12
6
2
12 No Connection
No Connection
No Connection
