Impulse 31
Transmitter Controls
BIND TH ST
N R N R
Reverse Switch
Allows you to
change the
direction of
steering (ST. REV)
and throttle (TH.
REV) controls.
(Default settings
are “N” for
steering and “R”
for throttle)
BIND TH ST
N R N R
POWER
ST. TRIM
TH. TRIM
ST. RATE
Adjusts the
neutral point of
the electronic
speed control
Throttle Trim
Adjust to make
the vehicle drive
straight with
no input at the
steering wheel
Steering Trim
Battery level Indicator
Solid Green: Battery
voltage is good
(Above 4V).
Flashing Green: Battery
voltage is critically low
(below 4V). Replace
batteries.
power Switch
Power on or off
the transmitter
POWER
ST. TRIM
TH. TRIM
ST. RATE
Steering Wheel
Control
steering.
Right and
Left steering
with ST. REV
Switch on N
(See ST. REV
switch)
Steering Rate
Adjusts the amount the
rudder moves when the
steering wheel is turned
left or right
POWER
ST. TRIM
TH. TRIM
ST. RATE
Throttle Trigger
Controls power
to the motor for
forward or reverse
(See TH. REV
switch)
Stop
Reverse
(when TH.
REV switch
on R) Forward
(when TH.
REV switch on R)
Rf Mode
The Pro Boat 2.4GHz transmitter
has a France RF Mode that
complies with French regulations.
The transmitter must be in France
mode when used outdoors in
France. At all other times, the
transmitter should be in Standard
mode.
france mode
Turn the wheel full left, pull the
trigger to full throttle and hold down
the bind button while turning on
the transmitter. The Green LED
will flash twice.
Standard mode
(Default preset set at factory)
Turn the wheel full right, pull the
trigger to full throttle and hold down
the bind button while turning on
the transmitter. The Green LED
will flash once.
6
