Pro Boat PRB4250B - Manual (Page 5)

Impulse 31
Installing the Battery pack(s)
1. Turn the latch so that the tab is parallel with the back
of the hull, then lift the hatch up and back from the
hull.
2. Remove the radio box cover. Where needed, install
the included self-adhesive hook strips on your battery
pack(s).
3. Remove the wing nut and cover from the battery
compartment.
4. Install the included hook and loop tape on the battery
packs. Install the batteries on the hook and loop strips
in the compartment, then place the included clear tube
on the screw to prevent the screw from cutting the
packs.
5. Install the cover over the pack(s) and tighten the wing
nut on the screw to hold the pack(s). Loosen the wing
nut and move the pack(s) forward or back to adjust
the center of gravity for your boat. Move the pack(s)
toward the bow so the bow rides lower in the water.
Move the pack(s) away from the bow so that the bow
rides higher in the water.
6. Connect the battery pack(s) to the ESC power
connectors.
7. Disassemble in reverse order.
4
1 2 3
Transmitter Battery Installation
Install 4 AA alkaline batteries
into the transmitter, following
the instructions provided for
your radio system.
3 1 2
5
Battery Safety precautions
• When using a Li-Po battery, always ensure the
Battery Chemistry Switch is in the ON position.
• Never discharge a Li-Po battery below 3V per cell.
• Always disconnect a battery from the ESC when
not in use.
• Avoid continually operating to LVC, as this could
result in damage to the battery.
5
