Using the swivel head
I At the starting clipping position of 0° (pointing
forward), turn the swivel head 45° or 90° to
the left or right to adjust the position of the
cutting element to the part of your head you
are clipping (fig. 6).
D Turn the swivel head left or right to the
desired clipping position. At each position you
will hear a ‘click’ (fig. 7).
Always adjust the position of the cutting element
by turning the swivel head. Do not turn the swivel
head by holding the cutting element or the comb
attachment.
Q The swivel head allows you to hold and use
the Clipper like a styling comb (fig. 8).
Do not turn the swivel head more than 90° to the
left or right.
B Push the ON/OFF switch up to turn on the
appliance.
□ Make sure that the flat part of the comb is
always in full contact with the scalp to obtain
an even result.
H Since all hairs do not grow in the same
direction, move the Clipper slowly over the
crown from different directions (i.e. upwards,
downwards and across) to achieve an even
result (fig. 9).
Q Always move the Clipper slowly against the
direction of hair growth.
Q Make overlapping passes over the head to
ensure that all hairs that should be cut are
cut.
fil As you clip different areas of your head,
adjust the position of the swivel head so that
the swivel head position is most comfortable
for you.
B For best results with curly, sparse or long
hair, use a styling comb to guide the hair
towards the Clipper.
[Q Turn the Clipper off regularly during clipping
and remove the hair comb to blow and/or
shake out hair that has accumulated.
When you remove the comb, the selected setting
does not change.
TIP:Write down the settings you have used to create
a certain hairstyle as a reminder for future clipping
sessions.
Table 1 Comb Settings
Comb
Barber
Setting
Remaining
Hair Length
# 1 1/8 ¡n./3mm
•
3/16 in./S mm
#2 9/32 in./7mm
m 3/8 ¡n./9mm
•
7/16 in./l Imm
#4 1/2 in./l3m m
#5 5/8 in./15mm
