Connecting to speakers and subwoofer
front
speaker
rear
speaker
subwoofer
- . • . .
.
...................................... .............. .....................................................
.
............... ................. ..
Front Left (FL)
biack
white
Front Right (FR)
biack
red
Center (C)
black
green
Surround Left (SL)
black
blue
Surround Right (SR)
black
grey
Positioning the speakers and subwoofer
Surround-left
(supplied)
Center (supplied)
Front-left
(supplied)
Front- right
(supplied)
SumtUnd-right
Printed in China
QS-MX3600-MX3700/37-I
