Specifications
5-2
Safety
This equipment meets the safety requirements of:
•
UL 1950
•
CSA C22.2 No. 950
•
EN 60950
•
IEC 950
•
EMI Requirements of FCC Part 15 Class A
•
EN 55022 Class A
•
VCCI Class I
•
EMC requirements of:
EN 50082-1
IEC 801-2 ESD
IEC 801-3 Radiated susceptibility
IEC 801-4 EFT
Service
MTBF (MHBK-217E)
>200,000 hrs.
MTTR
<0.5 hr.
Physical
Dimensions:
35.0 D x 44.0 H x 6.0 W centimeters
(13.8D x 17.4H x 2.4W inches)
Weight:
Unit: 2.7kgs.
(6lb)
Shipping: 3.6kgs.
(8lb)
Environment:
Operating Temperature
5 to 40
°
C
Storage Temperature
-30 to 90
°
C
Relative Humidity
5% to 95% non-condensing
It is the responsibility of the person who sells the system to which the module will be a
part to ensure that the total system meets allowed limits of conducted and radiated
emissions.
!
CAUTION
