LANVIEW LEDs
4-2
The function of the two System Status LEDs, System Management Bus (SMB) and
the CPU, are listed in Table 4-1.
The function of the INB receive LEDs are listed in Table 4-2.
The function of the INB transmit LEDs are listed in Table 4-2.
Table 4-1. System Status (SMB and CPU) LEDs
LED Color State Description
Green Functional Fully operational.
Yellow Crippled Not fully operational (i.e., one bad port).
Yellow/Green Booting Blinks yellow and green while booting.
Red Reset Normal power-up reset.
Red (Flashing) Failed Fatal error has occurred.
Off Power off Module powered off.
Table 4-2. INB Receive LEDs
LED Color State
Yellow (Flashing) Activity
Off No Activity
Table 4-3. INB Transmit LEDs
LED Color State
Green INB Link
Green (Flashing) Activity
Off No Activity
