7
54" Fabricated Deck Spindle Assembly - Parts List for Figure 3
Ref.
No. Part No. Description Qty.
1 00005763 Hex Nut, 7/16-14 1
2 00008495 Hex Cap Screw, 3/8-16 x 1-3/4 1
3 00011438 Hex Cap Screw, 3/8-16 x 1-1/2 12
4 00011925 Hex Cap Screw, 3/8-16, 4.00 1
5 00012158 Flat Washer, 3/8 12
6 00022560 Hex Nut, Flange Lock, 3/8-16 18
7 00060078 Grease Fitting, 1/4-28 x 3/16 2
8 00083192 Idler Washer 1
9 01000302 Shoulder Screw, 7/16-14 1
10 01000364 Hex Carriage Screw, 3/8-16, 1.75 1
11 01000372 Carriage Bolt, 3/8-16 x .75 Lg. 1
12 01000380 Flange Hex Nut, 3/4-16 3
13 01000387 Torsion Spring Idler 1
14 01000389 Lock Washer, 7/16 1
15 01000392 Flat Washer, .781 ID, 2.00 OD, .105 3
16 01000393 Flat Washer, .469 ID, .875 OD, .105 1
17 01000643 Carriage Bolt, 3/8-16 x 1 1
18 01000723 Flat Washer, .406 ID, 1.0 OD, .105 6
19 01003123 Spacer, .812 ID x .218 LG 4
20 01003245 Spacer, .39 ID x .625 OD x 2.75 1
21 01005737 Idler Arm Assembly, Deck Spindle includes: 1
01000308 Bearing 2
22 01003532 Spindle Assembly, Aluminum Fab Deck 3
23 01004415 Spacer, .760 ID x 2.000 OD x 1.1 4
24 01004478 Plate Support, Cast Aluminum Spindle 3
25 01005203 V Pulley, 5.774 OD 1
26 01005213 Hex Cap Screw, 3/4-16, 7.00 2
27 01005375 V Belt, A Section x 114.3 1
28 01005377 V Belt, B Section x 91.2 1
29 01005388 Hex Cap Screw, 3/4-16, 9.00 1
30 01005616 V Pulley, 5.00 OD 3
31 02003712 Spring Extension, .94 OD x 7.57 1
32 02003740 Idler Tension Handle Grip 1
33 02004195 Tension Spring Bracket 1
34 02004447 Idler Pulley, 4.06 OD w/Deep Flange 1
35 02005018 Hi-Lift Blade, 19.0, 0.756 3
36 02005077 Idler Pulley, 4.06 Dia. 1
37 02005079 Idler Pulley, 5.06 Dia. 1
38 02005509 Idler Arm Assembly includes: 1
01000308 Bearing 2
39 00002528 Hex Cap Screw, 3/8-16 x 2.00 1
