54" Fabricated Deck Assembly - Parts List for Figure 2
Ref.
No. Part No. Description Qty.
1 00012428 Lock Nut, Nylon Insert, 1/2-13 5
2 00014608 Lock Nut, Nylon Insert, 10-32 16
3 00017778 Phillips Head Screw, 10-32 16
4 00022560 Hex Nut, 3/8-16 Flange Lock 49
5 00083192 Idler Washer 1
6 01000343 Complete Wheel, 5.00 Dia. 4
7 01000372 Carriage Bolt, 3/8-16 x .75 Lg. 35
8 01000385 Front Roller 4
9 01000398 Wheel Spacer 2
10 01000643 Carriage Bolt, 3/8-16 x 1 8
11 01001745 Pin, 5/8 Dia. x 1.2 Lg. 4
12 01002010 Carriage Screw, 3/8-16 x 1.25 4
13 01003253 Spring Torsion, 0.4 ID x 2.16 LG 1
14 01003254 Defllector Chute Rod 1
15 01004304 Hex Index Washer Screw, 3/8-16, .5 8
16 01004684 Cover Support 2
17 01004707 Roller Mount Bracket 3
18 01005438 Outer Belt Cover Support Assembly 2
19 01005869 T-Handle Draw Latch 4
20 01006693 Deflector Chute 1
21 01006748 Deflector Chute Bracket 1
22 01008049 Carriage Bolt, 3/8-16 x 4.00 2
23 01008644 Finger Guard 1
24 01009296 Chute Baffle 1
25 01009842 Discharge Baffle Weldment 1
26 01010119 Nut, 1/2-13, Flangelock 2
27 02000109 Pillow Block 2
28 02002799 J-Hook w/ Threaded Roller 1
29 02004675 Baffle, 54" Adjustment 1
30 02004689 54" Deck Assembly 1
31 02004791 Left Hand Deck Weldment Mounting Plate 1
32 02004792 Right Hand Deck Weldment Mounting Plate 1
33 02004833 Shoulder Bolt, .625 x 3.00 x 3/8-16 2
34 02005106 Right Hand Front Adjustment Skirt 1
35 02005107 Left Hand Front Adjustment Skirt 1
36 02005144 Right Hand Belt Cover 1
37 02005145 Left Hand Belt Cover 1
38 712-0641 Hex Nut, M16-1.5 2
39 721-04041 Water Nozzle Adaptor 1
40 736-0760 Lock Washer, 17 x 23.8 x 1.95 2
41 737-04003C Deck Water Nozzle 2
