Appendix II Technical Specifications

Industry Standards

Complies with
• IEEE 802.1d: Spanning Tree Protocol

• IEEE 802.1Q: Tagged VLAN

• IEEE 802.3: 10 Base-T

• IEEE 802.3u: 100 Base-TX

• IEEE 802.3ab: 1000 Base-T

• IEEE 802.3ad: Link Aggregation

• IEEE 802.3z: 1000 Base-SX

• IEEE 802.3x: Flow Control

Certificate Standards

• FCC Class A

• CE Mark

• C-Tick

• UL

Interface

• 24 RJ45 UTP 10/100Mbps ports

• 2 expandable slots with two 1000Mbps Modules installed

• 1 RS232 serial interface

SNMP Management
(4 groups of RMON)

• Group 1-Ethernet Statistic

• Group 2-History

• Group 3-alarm

• Group 9-events

Virtual LAN

• Port-based VLAN

• Tagged VLAN

Spanning Tree Protocol

Yes

Flash ROM

2 M bits

Port Mirroring

Yes

Management Interface

• Web-based Interface

• RS232

• Telnet Console

• SNMP

Port Trunking

Up to 4 ports/trunk
