Chapter 3 Hardware Installation
8
Chapter 3 Hardware Installation
This chapter gives an in-sight on the hardware installation aspect from installing the physical
cables to resetting the device.
3.1 Physical Setup for Compex SGX3226
Compex SGX3226 is ideally suitable for office environment usage, which can be
either installed on a flat surface (desktop) or mounted on a 19-inch rack. The
following steps illustrate how a proper installation has to be done.
3.1.1 Desktop Installation
1. Unpack Compex SGX3226.
2. Remove the backing strip from the 4 rubber feet and attach to the
underside of the switch chassis firmly.
3. Place it with a power outlet located nearby. Be sure to set the device
with sufficient space for heat ventilation.
4. The surface to place Compex SGX3226 should be clean, smooth, level
and sturdy.
5. Ensure there is enough space around the unit to allow attachment of
network cables.
6. Connect the power cord to the power socket on the rear panel of
Compex SGX3226.
3.1.2 Rack-Mounted Installation
1. Position one bracket to align with the holes on one side of Compex
SGX3226 and secure it with the smaller bracket screws (1/8-inch
diameter). Then attach the other bracket to another side of it.
2. After attaching both mounting brackets, position the device in the rack
by lining up the holes in the brackets with the appropriate holes on the
rack. Secure it to the rack using the rack-mounting screws (5/16 inches
diameters) with a screwdriver.
