Compaq DPW Enhanced a-Series & au-Series
6
Step 5a
Internal Storage (continued)
Packaged systems include a 9.1 GB Wide Ultra-2 SCSI hard disk drive (SN-PBXRW-SC).
SCSI disk drives
SN-PBXRW-SC 9.1 GB Wide Ultra-2 LVD SCSI 7200 RPM hard disk drive, 1.0 inch drive
SN-PBXRW-TB 18.2 GB Wide Ultra-2 LVD SCSI 7200 RPM hard disk drive, 1.0 inch drive
SN-PBXRW-RB 4.3 GB Wide Ultra-2 LVD SCSI 10K RPM hard disk drive, 1.0 inch drive
SN-PBXRW-VA 9.1 GB Wide Ultra-2 LVD SCSI 10K RPM hard disk drive, 1.0 inch drive
SN-PBXRW-WA 1 18.2 GB Wide Ultra-2 LVD SCSI 10K RPM hard disk drive, 1.6 inch drive (includes fan kit)
SN-PBXRW-WB 18.2 GB Wide Ultra-2 LVD SCSI 10K RPM hard disk drive, 1.0 inch drive
SN-PBXRW-XA 36.4 GB Wide Ultra-2 LVD SCSI 10K RPM hard disk drive, 1.6 inch drive
1. Maximum one per system, supported in 5.25-inch removable media bays only.
Removable Media
Systems include one 5.25-inch 32X CD-ROM drive and supports two additional 5.25-inch removable media devices.
Note: 5.25-inch removable media bays also support hard disk drives.
Maximum of one additional ATAPI device supported per system.
SN-PBXRV-AA 6X/32X ATAPI DVD-ROM Drive (Data Device only) (UNIX, Windows NT only)
SN-PBXRX-CA 100 MB ATAPI ZIP Drive
SN-TLZ10-LK 12/24 GB 4mm DAT internal SCSI tape drive, 1.6-inch front accessible bay
SN-TLZ09-LK 4/8 GB 4mm DAT internal SCSI tape drive, 1.6-inch front accessible bay
Step 5b
External Storage
Tabletop DAT Tape Drives
Tabletop tapes require SN-KZPBA-CA SCSI adapter, they are not supported on same adapter as internal storage.
TLZ09-DC 4/8 GB 4mm DAT external tabletop SCSI tape drive.
Cables/Adapters Required: Wide to Narrow terminator adapter included.
Requires BC09D-03/06 (3/6 foot) 50 pin HD to 50 pin LD cable.
DS-TLZ10-DB 12/24 GB 4mm DAT external tabletop SCSI tape drive.
Cables/Adapters Required: Requires BN36A-0B Wide to Narrow terminator adapter.
Requires BC09D-03/06 (3/6 foot) 50 pin HD to 50 pin LD cable.
Controllers/Adapters
au-Series systems running Tru64 UNIX V4.0D and OpenVMS 7.2-1 support one RAID controller (SN-KZPAC-xx).
a-Series and au-Series systems support two additional UltraSCSI adapters for a system maximum of three (including the
onboard adapter). The second optional controller must be installed on the secondary PCI bus.
Maximum controllers/adapters supported per system a Series au Series
SN-KZPBA-CA 1 Q-Logic 1040B Wide Ultra SCSI adapter—uses 1 PCI 32-bit slot 2 2
SN-KZPBA-CB 1 1 port UltraSCSI Differential adapter—uses 1 PCI slot 2 2
SN-KZPAC-AA 2 1 port RAID controller, 4MB EDRAM cache—uses 1 PCI 32-bit
slot 1 1 3
SN-KZPAC-CA 2 3 port RAID controller 4MB EDRAM cache—uses 1 PCI 32-bit
slot, third port uses one additional PCI bulkhead slot, requires
BN31K-0E bulkhead assembly kit and SCSI cable. 1 1 3
SN-KZPAC-CB 2 Same as –CA with 8MB EDRAM cache 1 1 3
