Compaq DPW Enhanced a-Series & au-Series
2
Step 1
Compaq DPW Workstations
Compaq DPW Workstations a-Series 500a, 600a—Windows NT, and Compaq DPW au-Series Workstations 500au,
600au—Tru64 UNIX and OpenVMS feature
Short tower enclosure with
Alpha microprocessor 21164 500/600 MHz CPU
Compaq DPW Workstations a-Series, or
Alpha microprocessor 21164 500/600 MHz CPU
Compaq DPW Workstations au-Series.
Optional 4 MB cache
Five I/O slots
Two PCI
Three PCI/ISA
Three DIMM banks (six slots) (1.5 GB maximum)
Six storage bays
Two 3.5-inch x 1-inch hard disk drive bays
One dedicated floppy disk bay
One dedicated 5.25-inch CD-ROM removable
media bay
Two additional removable media bays
300 W power supply
Onboard Qlogic Wide Ultra SCSI Adapter
Onboard 16-bit audio (not supported on OpenVMS)
10/100 BaseT Ethernet
Twisted pair (ThinWire—optional)
1.44 MB diskette drive.
32X CD-ROM drive.
Factory installed software
Compaq DPW a-Series Windows NT 4.0 includes
Windows NT base license, or
Compaq DPW au-Series Tru64 UNIX V4.0F
includes Tru64 UNIX Performance Personal
Workstations License Package with Tru64 UNIX
base 2 user license, and Open3D for Tru64 UNIX
License, or
Compaq DPW au-Series OpenVMS 7.2-1 includes
OpenVMS System Value License Package with
OpenVMS Alpha base 2 user license, NAS Client
150 Traditional License, and Open3D for OpenVMS
License.
Base Systems
Selection of a System and Country Kit is mandatory.
a-Series—Windows NT System Building Blocks (500 MHz and 600 MHz)
Order Number CPU Operating System Memory / Cache / Disk Graphics Controller Country Kit
SN-B3DCP-A2 1 500a Windows NT 4.0 0 MB / 0 MB / 0 GB Mandatory UltraSCSI Mandatory
SN-B3ECP-A2 1 600a Windows NT 4.0 0 MB / 0 MB / 0GB Mandatory UltraSCSI Mandatory
a-Series—Windows NT Packaged Systems (500 MHz and 600 MHz)
SN-B3DCP-SD 500a Windows NT 4.0 128 MB / 0 MB /9.1 GB Mandatory UltraSCSI Mandatory
SN-B3DCP-SH 500a Windows NT 4.0 512 MB / 0 MB / 9.1 GB Mandatory UltraSCSI Mandatory
SN-B3ECP-SB 600a Windows NT 4.0 64 MB / 0 MB / 9.1 GB Mandatory UltraSCSI Mandatory
SN-B3ECP-SD 600a Windows NT 4.0 128 MB / 0 MB / 9.1 GB Mandatory UltraSCSI Mandatory
SN-B3ECP-SH 600a Windows NT 4.0 512 MB / 0 MB / 9.1 GB Mandatory UltraSCSI Mandatory
au-Series—Tru64 UNIX System Building Blocks (500 MHz and 600 MHz)
Order Number CPU Operating System Memory / Cache Graphics Controller Country Kit
SN-B3DCU-A2 1 500au Tru64 UNIX 0 MB / 0 MB / 0 GB Optional UltraSCSI Mandatory
SN-B3ECU-A2 1 600au Tru64 UNIX 0 MB / 0 MB / 0 GB Optional UltraSCSI Mandatory
au-Series—Tru64 UNIX Packaged Systems (500 MHz and 600 MHz)
SN-B3DCU-SB 500au Tru64 UNIX 64 MB / 0 MB / 9.1 GB Optional UltraSCSI Mandatory
SN-B3DCU-SD 500au Tru64 UNIX 128 MB / 0 MB / 9.1 GB Optional UltraSCSI Mandatory
SN-B3DCU-SH 500au Tru64 UNIX 512 MB / 0 MB / 9.1 GB Optional UltraSCSI Mandatory
SN-B3ECU-SB 600au Tru64 UNIX 64 MB / 0 MB / 9.1 GB Optional UltraSCSI Mandatory
SN-B3ECU-SD 600au Tru64 UNIX 128 MB / 0 MB / 9.1 GB Optional UltraSCSI Mandatory
SN-B3ECU-SH 600au Tru64 UNIX 512 MB / 0 MB / 9.1GB Optional UltraSCSI Mandatory
