Specification – Hyundai H-CDM8042 User Manual
Page 25
25
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General
Power supply:
12 V DC
Current consumption:
max. 15 A
Maximum power output:
50 W x 4 channels
Dimensions (L x W x H):
178 x 175 x 50 mm
Working temperature range:
-10º - +60º
FM Stereo Radio
Frequency range:
65 74 / 87.5 - 108.0 MHz
Usable sensitivity (S/N = 30 dB):
10 dB
Preset memory stations:
18
MW and LW section
Frequency range:
522 kHz - 1620 kHz
Preset memory stations:
12
Audio specification
Maximum output:
2 Vrms (+/- 3 dB)
Frequency response:
20 Hz - 20 KHz
S/N ratio(A-vtd):
> 65 dB
DSP sound effect:
Classic, Rock, Pop, Flat
Line out
Output:
CD max 2000 mV
