Table 1E — 40RMQ Physical Data, SI
UNIT 40RMQ
008
012
016
NOMINAL CAPACITY (kW)
26
35
52
OPERATING WEIGHT (kg)
Base Unit with TXV
175
194
323
Plenum
44
44
63
FANS
Qty...Diam. (mm)
1...381
1...381
2...381
Nominal Airflow (L/s)
1604
1888
2831
Airflow Range (L/s)
1203-2006
1416-2360
2124-3539
Nominal Motor kW (Standard Motor)
208/230-1-60
1.79
—
—
208/230-3-60 and 460-3-60
1.79
1.79
2.76
575-3-60
1.49
1.49
2.24
230-3-50, 400-3-50
1.79
2.16
2.16
Motor Speed (r/s)
208/230-1-60
28.8
—
—
208/230-3-60 and 460-3-60
28.8
28.8
28.8
575-3-60
28.8
28.8
28.8
230-3-50, 400-3-50
23.8
23.8
23.8
REFRIGERANT
R-22
Operating charge (kg)
(approx per circuit)*
1.36
0.91/0.91
1.36/1.36
DIRECT-EXPANSION COIL
Max Working Pressure (kPag)
2999
Face Area (sq m)
0.77
0.93
1.64
No. of Splits
1
2
2
No. of Circuits per Split
15
9
16
Split Type...Percentage
—
Face...50/50
Rows...Fins/m
3...591
4...591
4...591
STEAM COIL
Max Working Pressure (kPag at 204.4 C)
1207
Total Face Area (sq m)
0.62
0.62
1.24
Rows...Fins/m
1...355
1...355
1...394
HOT WATER COIL
Max Working Pressure (kPag)
1034
Total Face Area (sq m)
0.62
0.62
1.24
Rows...Fins/m
2...335
2...335
2...335
Water Volume
(L)
31.4
52.6
(m
3
)
0.031
0.052
PIPING CONNECTIONS,
Quantity...Size (in.)
DX Coil — Suction (ODF)
1...1
1
⁄
8
2...1
1
⁄
8
2...1
1
⁄
8
DX Coil — Liquid Refrigerant (ODF)
1...
5
⁄
8
2...
5
⁄
8
2...
5
⁄
8
Steam Coil, In (MPT)
1...2
1
⁄
2
1...2
1
⁄
2
Steam Coil, Out (MPT)
1...1
1
⁄
2
1...1
1
⁄
2
Hot Water Coil, In (MPT)
1...1
1
⁄
2
1...1
1
⁄
2
1...2
Hot Water Coil, Out (MPT)
1...1
1
⁄
2
1...1
1
⁄
2
1...2
Condensate (Male PVC)
1...1
1
⁄
4
ODM/1 IDF
FILTERS
Throwaway — Factory Supplied
Quantity...Size
4...406 x 610 x 51
4...406 x 508 x 51
4...406 x 610 x 51
Access Location
Either Side
LEGEND
TXV — Thermostatic Expansion Valve
*Units are shipped without refrigerant charge.
