Table 5 — Electrical Data, Alternate Motors
UNIT
V*-PH-HZ
VOLTAGE
LIMITS
FAN MOTOR
POWER SUPPLY
Hp
FLA
Minimum
Circuit Amps
MOCP
40RM
007
208/230-1-60
187-253
2.4
11.0
13.8
20
208/230-3-60
187-253
2.9
7.5
9.4
15
460-3-60
414-528
2.9
3.4
4.3
15
575-3-60
518-632
2.0
2.4
3.0
15
40RM
40RMQ
40RMS
008
208/230-3-60
187-253
2.9
7.5
9.4
15
460-3-60
414-528
2.9
3.4
4.3
15
575-3-60
518-632
3.0
3.8
4.8
15
230-3-50
207-253
2.9
7.5
9.4
15
400-3-50
360-440
2.9
3.4
4.3
15
40RMS
010
208/230-3-60
187-253
2.9
7.5
9.4
15
460-3-60
414-528
2.9
3.4
4.3
15
575-3-60
518-632
3.0
3.8
4.8
15
230-3-50
207-253
2.9
7.5
9.4
15
400-3-50
360-440
2.9
3.4
4.3
15
40RM
40RMQ
40RMS
012
208/230-3-60
187-253
3.7
10.6
13.3
20
460-3-60
414-528
3.7
4.8
6.0
15
575-3-60
518-632
3.0
3.8
4.8
15
230-3-50
207-253
5.0
14.4
18.0
30
400-3-50
360-440
5.0
7.2
9.0
15
40RM
40RMS
014
208/230-3-60
187-253
3.7
10.6
13.3
20
460-3-60
414-528
3.7
4.8
6.0
15
575-3-60
518-632
5.0
5.6
7.0
15
230-3-50
207-253
5.0
14.4
18.0
30
400-3-50
360-440
5.0
7.2
9.0
15
40RM
40RMQ
40RMS
016
208/230-3-60
187-253
5.0
15.2/14.4
19.9/18.0
30/30
460-3-60
414-528
5.0
7.2
9.0
15
575-3-60
518-632
5.0
5.6
7.0
15
230-3-50
207-253
5.0
14.4
18.0
30
400-3-50
360-440
5.0
7.2
9.0
15
40RM
40RMS
024
208/230-3-60
187-253
7.5
22.0/21.0
27.5/26.3
45/45
460-3-60
414-528
7.5
10.5
13.1
20
575-3-60
518-632
7.5
7.6
9.5
15
230-3-50
207-253
7.5
21.0
26.3
45
400-3-50
360-440
7.5
10.5
13.1
20
40RM
40RMS
028
208/230-3-60
187-253
10.0
26.4/25.0
33.0/31.3
55/55
460-3-60
414-528
10.0
12.5
15.6
25
575-3-60
518-632
10.0
9.6
12.0
20
230-3-50
207-253
10.0
25.0
31.3
55
400-3-50
360-440
10.0
12.5
15.6
25
LEGEND
FLA
— Full Load Amps
MOCP — Maximum Overcurrent Protection
*Motors are designed for satisfactory operation within 10% of nomi-
nal voltages shown. Voltages should not exceed the limits shown in
the Voltage Limits column.
NOTES:
1. Minimum Circuit Amp and MOCP values are calculated in
accordance with NEC (National Electrical Code) (U.S.A. stand-
ard), Article 440.
2. Motor FLA values are established in accordance with UL (Under-
writers’ Laboratories) Standard 1995 (U.S.A. standard).
3. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply volt-
age is greater than 2%. Use the following formula to determine
the percentage of voltage imbalance.
% Voltage Imbalance
max voltage deviation from average voltage
= 100 x
average voltage
EXAMPLE: Supply voltage is 400-3-50.
AB = 393 v
BC = 403 v
AC = 396 v
393 + 403 + 396
Average Voltage =
3
1192
=
3
= 397
Determine maximum deviation from average voltage.
(AB) 397 − 393 = 4 v
(BC) 403 − 397 = 6 v
(AC) 397 − 396 = 1 v
Maximum deviation is 6 v.
Determine percent voltage imbalance.
6
% Voltage Imbalance = 100 x
397
= 1.5%
This amount of phase imbalance is satisfactory as it is below the
maximum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is more than
2%, contact your local electric utility company immediately.
