Routine Service and Maintenance
6. Check hydraulic hoses.
Hydraulic oil under pressure can penetrate body tissue causing serious injury and
possible death. When troubleshooting a hydraulic system for leaks, always use cardboard
or wood as a detector. DO NOT USE YOUR BARE HANDS. If you are injected with
hydraulic oil or any other fluids, immediately seek treatment by a doctor trained in the
treatment of penetrating fluid injuries.
a. Fully raise the loader arm, and secure the safety support.
b. Open the front service cover and secure with the safety support lock pin.
Figure 4–5 Install Safety Support
c. Press the lock button on the upper inspection panel locks, which will release the panel
locks (Item 2, Figure 4–6). Remove the inspection panel (Item 1, Figure 4–6).
Figure 4–6 Remove Upper Inspection Panel
WARNING
