3-6
Pre-Start Inspection and Operation
Figure 3–5 Loader Arm Lift Cylinder Base Lubrication Point
NOTE: Extremely dusty or dirty working conditions may require more frequent service/
replacement.
Make sure to install the cylinder lock before performing any service work underneath the
raised loader arm assembly.
2034
CAUTION
