Any maintenance work should only be carried out by qualified technicians.

To ensure the continuous rotation of the rotating gobos and linear motion of the lens for focusing, it is
recommended that the bearings for the rotating gobos and the 3 shafts for the focusing lens holder be
lubricated periodically, preferably every two months. Use only high quality, high-temperature resistant
grease instead of any type of oil. When lubricating the bearings, a syringe with a fine needle is the
easiest way to introduce the grease to the bearings around each gobo.

To ensure the reliability of the projector it should be kept clean. It is recommended that the fans
should be cleaned every 15 days. The lens and dichroic colour filters should also be regularly cleaned
to maintain an optimum light output.

Do NOT use any type of solvent on dichroic colour filters.

Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or
particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics. A soft cloth
and typical glass cleaning products should be used in cleaning. It is recommended to clean the
external optics at least once every 20 days and clean the internal optics at least once every 30 / 60
days.

Do not use any organic solvent, e.g. alcohol, to clean the reflector mirror, dichroic colour
filters or housing of the apparatus.

PROBLEM

POSSIBLE CAUSE

ACTION

The projector doesn’t switch
on

-The power supply is not
present

-The lamp doesn’t work

Check the fuse on the power
socket.

Replace the lamp.

The lamp comes on but the
projector doesn’t respond to
the controller

-Wrong DMX configuration

and/or start address
- Defective DMX cable

Make sure that the projector is
correctly configured.

Replace or repair the DMX cable.

The projector only functions
intermittently

-The fan has failed

Make sure the fan is working and
not dirty.

Defective projection

-The lens is broken

-Dust or grease on lenses

Check the lenses are not broken.

Remove dust or grease from the

lenses.

The projected image
appears to have a halo

-Installation of the lamp is not
correct

-Dust or grease

contamination on the optics.

Make sure the lamp is installed
correctly.

Carefully clean the optical group

lenses and the projector

components.

The beam appears dim

-Dust or grease contamination
on the optics.

-The lamp is at the end of its

life

Check the optics is clean.

Replace with a new lamp of the

specified type and rating.

Solo 575 Manual_en.doc

15/24

TROUBLESHOOTING

KEEPING THE PROJECTOR CLEAN

LUBRICATION
