9 Gobo
Rotation
000-120 (Rotating gobo) 0~540º index
121-127 (Rotating gobo) Rotation speed 1(slowest)
128-135 (Rotating gobo) Rotation speed 2
136-143 (Rotating gobo) Rotation speed 3
144-151 (Rotating gobo) Rotation speed 4
152-159 (Rotating gobo) Rotation speed 5
160-167 (Rotating gobo) Rotation speed 6
168-175 (Rotating gobo) Rotation speed 7
176-183 (Rotating gobo) Rotation speed 8 (fastest)
184-191 (Rotating gobo) stop rotating
192-199 (Rotating gobo) reverse rotation speed 1(slowest)
200-207 (Rotating gobo) reverse rotation speed 2
208-215 (Rotating gobo) reverse rotation speed 3
216-223 (Rotating gobo) reverse rotation speed 4
224-231 (Rotating gobo) reverse rotation speed 5
232-239 (Rotating gobo) reverse rotation speed 6
240-247 (Rotating gobo) reverse rotation speed 7
248-255 (Rotating gobo) reverse rotation speed 8 (fastest)
10 Pan & Tilt
Speed
000-255 Adjust Pan&Tilt speed
11 Pan Fine
(16Bit)
000-255 Adjust Pan in 16Bit resolution
12 Tilt Fine
(16Bit)
000-255 Adjust Tilt in 16Bit resolution
13 Gobo
Rotation Fine
000-255 Adjust gobo rotation in 16Bit resolution
14 Control 000-048 Reserve
049-080 Reset
081-112 Reserve
113-144 Turn lamp off（stay 10 seconds）
145-223 Reserve
224-255 Turn lamp on（see remark below）
Remark:
If you intend to turn on/off the lamp via the 14 th channel of the controller, don’t attempt to push the
handle of 14 th channel to value 224-255 immediately after turning it off, or push the handle to value
224-255 to wait it cooling. Under these 2 circumstances, the lamp can not be turned on. The right
operation is: turn it off---cool down---push the handle to turn it on.
If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes
damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this
would normally indicate that it is reaching the end of its life and it should be changed at once, aged
lamps run to the extremity of their life might explode. If the projector does not function, check the
fuses on the power socket of the projector, they should only be replaced by fuses of the same
specification
(200/220/230/240V: 6.35x32 T10A/250V; 100/120V: 6.35x32 T15A/250V) . On
the PCBs inside the projector there are also 3 fuses. They are 1 fuse F2A／250V 5mmx20mm on Pan
and Tilt PCB and 1 fuse F2A／250V 5mmx20mm on SLAVE PCB. Should these be damaged call a
qualified technician before replacement. The projector has thermal protection device that will switch
off the projector in case of overheating, should either of these operation, check that the fans are not
blocked, and if they are dirty clean them before switching on the projector again. Check that the fans
are operational, if not call a qualified technician.
Solo 575 Manual_en.doc 14/24
MAINTENANCE
