OmniSistem PR Solo 250 - Manual (Page 2)

solo 250 manual_last revision_en.doc 2/16
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
SETUP OPTIONS-PROJECTOR CONFIGURATIN 6
TO SET THE DMX START ADDRESS 7
DMX CONTROL CHANNEL FUNCTIONS 8
STAND-ALONE MODE & MASTER/SLAVE MODE 9
CHANGING THE GOBOS 9
LUBRICATION 9
MAINTENANCE 10
KEEPING THE PROJECTOR CLEAN 10
TROUBLESHOOTING 10
TECHNICAL DATA 11
ELECTRICAL DIAGRAM 12
COMPONENT ORDER CODES 13
CHANGING THE OPERATION VOLTAGE AND/OR FREQUENCY 14
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every apparatus is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the
apparatus are in good condition before your installation and use. Should there be any damage caused by transportation, consult
your dealer and do not use the apparatus. But any damage caused by improper use will not be assumed by the manufacturer
and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Mounting Bracket (2 PCS)
M8x25 screw for mounting brackets (4 PCS)
Power-cord (1 PCS)
XLR cable with XLR socket and XLR plug (1 PCS)
Safety cord (1 PCS)
Spare gobos (4 PCS)
This manual (1 PCS)
Thank you for purchasing our product SOLO 250, PR-2255.
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future
reference.
The SOLO 250 is an innovative projector with an elegant housing, which is made from high intensity
and heat–resistant complex plastic. SOLO 250 complies to CE norms and standards and uses
international protocol DMX 512. SOLO 250 can be used as a stand-alone unit, mutual units
connecting with each other for synchro master/slave or linked to a controller, so it is suitable for many
different applications.
SOLO 250 features 9 colours, 7 interchangeable rotating gobos, and an independent adjustable
strobe/shutter, prism effect and remote focus. It can be setup easily with the touch-switches and a
digital display screen.
ACCESSORIES
INDEX
INTRODUCTION
