OmniSistem PR Solo 250 - Manual (Page 13)

solo 250 manual_last revision_en.doc 13/16
NO. NAME PART NO. REMARK
1 TRANSFORMER 040030301 20V 50W / 230V 300W
2 THERMOSTAT 190010065 75 10A 250W
3 CAPACITOR 140010045 50µF 370V
4 BALLAST 040070053 230V/50-60Hz, 250W/3.6A
5 THERMOSTAT 190010054 95 10A
6 IGNITOR 040090016 220V AC 50Hz
7 LAMP 100050018 MSD 250W
8 FAN 030060035 KD2409PTB-6
9 FAN 030069006 KD2408PTB1-6
MOTOR 1 MOTOR 030040052 23HS0015L
MOTOR 2 MOTOR 030040053 23HS2029L
MOTOR 3 MOTOR(2pcs) 030040084 17HS0002-59L
MOTOR 4 MOTOR 030040085 17HS0002-61L
MOTOR 5 MOTOR(4pcs) 030040101 42BYGH004-1
MOTOR 6 MOTOR 030040105 42BYGH004-4(2-axis)
A1~A7 IC 170050010 DRIVER CHIPS
A8 IC 170110004 DRIVER CHIP
A9 IC 170050001
ARITHMETIC AMPLIFIER
CHIP
A10 IC 170110004 DRIVER CHIP
B1 IC 170040014 TTL LOGICAL CHIP
B2~B7 IC 170170037 D/A REVERSION CHIP
B8 IC 170040014 TTL LOGICAL CHIP
B9~B11 IC 170170037 D/A REVERSION CHIP
B12-B13 IC 170040014 TTL LOGICAL CHIP
C1 IC 170170039 STABLE-VOLTAGE CHIP
C2 IC 170170012
BUS CHIP FOR
RECEIVING/TRANSMITTING
C3 IC 170040032 EEPROM
D1 IC 230040120 MICROPROCESSOR
/ PAN DRIVE BELT 290151217 HTD309-3M-103Z
/ TILT DRIVE BELT 290151218 HTD420-3M-140Z
Note: You may order all parts of the SOLO 250 besides the table listed above. When ordering please
state the exact name and part no.. Repairs must be carried out by a qualified technician.
COMPONENT ORDER CODES
