Remark:
If you intend to turn on/off the lamp via the 14 th channel of the controller, don’t attempt to push the
slide bar of 14 th channel to value 224­255 immediately after turning it off, or push the slide bar to
value 224­255 to wait it cooling. Under these 2 circumstances, the lamp can not be turned on. The
right operation is: turn it off­­­cool down­­­push the slide bar to turn it on.
250­255 Reverse rotation speed 10(fastest)
5 Pan 000­255 Pan rotation
6 Tilt 000­255 Tilt rotation
7 CYM­Cyan
000­127 Cyan enter gradually
128­187 Cyan from light to dark
188­197 Stop
198­255 Cyan from dark to light
8 CYM­Yellow
000­127 Yellow enter gradually
128­187 Yellow from light to dark
188­197 Stop
198­255 Yellow from dark to light
9 CYM­Magenta
000­127 Magenta enter gradually
128­187 Magenta from light to dark
188­197 Stop
198­255 Magenta from dark to light
10 Effect Wheel
000­042 White
043­084 Effect 1
085­127 Effect 2
128­255 Fresnel effect index
11 Pan & Tilt Speed 000­255 From fast to slow
12 Pan Fine 000­255 Pan rotation in 16 Bit precision
13 Tilt Fine 000­255 Tilt rotation in 16 Bit precision
14
Control
(when ext.
channels disabled,
this channel
performed by
channel 12)
000­048 Reserved
049­080 Reset
081­112 Reserved
113­114 Lamp off
115­223 Reserved
224­255 Lamp on
