OmniSistem PR Design 250 - Manual (Page 2)

Design 250 EN.doc 2/26
SECTION PAGE
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER CONNECTIONS 5
CONTROL CONNECTIONS 5
DMX TERMINATOR 6
DMX CONTROL CHANNEL FUNCTIONS 7
TO SET THE DMX START ADDRESS 8
SETUP OPTIONS -PROJECTOR CONFIGURATION 8
LED INDICATION 9
STAND-ALONE MODE 9
MASTER/SLAVE MODE 9
OPERATION MENU 10
USER GUIDE 19
MAINTENANCE 20
KEEPING THE PROJECTOR CLEAN
20
TROUBLESHOOTINGS 20
TECHNICAL DATA
22
ELECTRICAL DIAGRAM 23
COMPONENT ORDER CODES 24
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of this manual we reserve the
right to change specifications in the course of product improvement. The publishers cannot be held responsible
for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or
the unit is in good condition before installation and use. Should there be any damage caused by transportation,
consult your dealer and do not use the unit. Any damage caused by improper use will not be assumed by the
manufacturer and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
Safety cord (1PCS)
Barndoors (1SET) (including 4 copper stand-offs, 4 screws and 4 flat washers)
This manual (1PCS)
Thank you for purchasing the Design 250, PR-1250.
This product manual contains important information about the safe installation and use of
this projector. Please read and follow these instructions carefully and keep this manual in a
safe place for future reference.
The Design 250 is a projector of innovative, compact, silent colour changing, capable of
extraordinary performances in terms of colour mixing, reliability and versatility. The product
complies to CE norms and standards and uses international protocol DMX 512. The Design
250 is particularly suitable for television studios and theatres, stage lighting, limelights,
backdrops, inside or outside shops and shopping centres, sport centres and almost all
architectural applications.
The Design 250 features 6 kinds of colour filters for CYM colour mixing and 2 blades for
shutter/dimmer. The product has light level sensor track system which can adjust the status
of product automatically. And the projector can be setup easily via the touch-switches and
LCD display.
ACCESSORIES
INDEX
INTRODUCTION
