NAME PART
NO.
NUMBER REMARK
TRANSFORMER 040030038
1
100~245V
50/60Hz
THERMOSTAT 190010054
1
95°C/10A/250V
CAPACITOR 140010011
1
20µF
AC
370V
BALLAST 040070022
1
150W
1.8A
IGNITOR 040090016
1
230V/50-60Hz
RELAY 192010026
1
LAMP 100050037
1
CDM-SA/T
150W/942
FUSE
270041020
1
FSD 5*20 6.3A
FUSE 270041052
1
6.35*32
T7A/250
COVER GLASS
080090021
1
CYAN MOTOR
030040078
2
17HS0001-06KL 5*25*11.3
YELLOW MOTOR
030040078
2
17HS0001-06KL 5*25*11.3
MAGENTA MOTOR
030040077
2
17HS0001-05KL 5*12*11.3
SHUTTER MOTOR
030040077
2
17HS0001-05KL 5*12*11.3
016330054 1
HOLDER
CYAN AND HOLDER
090100020
1
DICHROIC COLOUR FILTER
016330053 1
HOLDER
YELLOW AND HOLDER
090100021
1
DICHROIC COLOUR FILTER
016330053 1
HOLDER
MAGENTA AND HOLDER
090100022
1
DICHROIC COLOUR FILTER
LAMP CONTROL PCB
230020167
1
RECTIFICATION PCB
230020168
1
SIGNAL PCB
230020169
1
DISPLAY PCB
230020171
1
MOTOR DRIVE PCB
230020172
1
NOTE: You may order all parts of the Design 150 PRO besides the table listed above. When
ordering please state the exact name and part no.. Repairs must be carried out by a
qualified technician.
COMPONENT ORDER CODES
