OmniSistem LED Par 64 (4 Channel) - Manual (Page 5)

LED PAR 64 PRO - 4 CH. Manual 2010-01-01
DMX CONTROL SETTINGS
CHANNEL FUNCTION
CH. 1
RGB DIMMER/STROBE
CH. 2 RED DIMMER
CH. 3 GREEN DIMMER
CH. 4 BLUE DIMMER
DIP SWITCH SETTINGS
ON OFF FUNCTION
1, 10 2,3,4,5,6,7,8,9 DMX - 512
5,9 1,2,3,4,6,7,8,10 SOUND ACTIVATE ONLY
8 1,2,3,4,5,6,7,9,10 SOUND ACTIVE (ADJUST SPEED WITH 1,2,3,4)
1 2,3,4,5,6,7,8,9,10 RED
2 1,3,4,5,6,7,8,9,10 GREEN
3 1,2,4,5,6,7,8,9,10 BLUE
5 1,2,3,4,6,7,8,9,10 STROBE (ADJUST SPEED WITH 1,2,3,4)
6 1,2,3,4,5,7,8,9,10 RGB DIMMER (ADJUST SPEED WITH 1,2,3,4)
7 1,2,3,4,5,6,8,9,10 RGB CHASE (ADJUST SPEED WITH 1,2,3,4)
