Test Result 4: Wiring diagram (WIREMAP) display
when there is an open circuit at the far-end of cable.
Wire map:fail
R: 12 x45 x78 id1
Iiiiiiii
M: 12345678
" R:" line "3" and "6" pins location display "x", it indicates an open circuit in
far-end plug "3" and "6” pins and the open circuit is located nearby the far-end
plug.(The open circuit should be located within 10% cable length if it is
measured from the far-end plug)
Note: Because network cable is made of pair cores, if there is open circuit,
it will show faults in pairs, just as above "3" &" 6". it means either "3" pin or
"6" pin exsits an open circuit, or both "3" and "6" exsit an open circuit.
Test Result 5: Wiring diagram (WIREMAP) display when there is an open
circuit at the near-end of cable.It will display wiring diagram(WIREMAP) as
follows if there is an open circuit at the near-end plug of the cable:
Wire map:fail
R: 12345678 id1
Iiiiiiii
M: 12 x45678
"M:" line "3" pin location displays "x", it indicates an open circuit at near-end
plug "3" pin and the open circuit is located nearby the near-end plug. (The
open circuit should be located within 10% cable length if it is measured from
the near-end plug)
