10.3 Hydraulic Plumbing
From this point on in the installation the booms will be inoperative until the
hydraulics are fully installed.
1. After the NORAC valve is mounted, the hydraulic hoses and fittings can be plumbed. The
plumbing for the hydraulic circuit is shown schematically in Figure 3.
2. Disconnect the tilt cylinder “raise” lines from the sprayer valve block and insert the 6FJXR-
6MJT tees (F03). Reconnect the “raise” lines.
3. Connect two hoses (H01) to the free end of the tees (F03).
4. Connect the other end of the hoses (H01) to the “B ports” on the NORAC valve block.
5. Connect the two hoses (H02) to the pressure and tank ports on the NORAC valve block.
Route these hoses to the front of the sprayer at the hitch. There are quick connect fittings
on the end of hoses to connect to the remotes on the tractor.
