10.3 Hydraulic Plumbing
From this point on in the installation the booms will be inoperative until the
hydraulics are fully installed.
1. After the NORAC valve is mounted, the hydraulic hoses and fittings can be plumbed. The
plumbing for the hydraulic circuit is shown schematically in Figure 3.
2. Disconnect the tilt cylinder “raise” lines from the sprayer valve block and insert the 6FJXR-
6MJT tees (F04). Reconnect the “raise” lines.
3. Connect two hoses (H01) to the free end of the tees (F04).
4. Connect the other end of the hoses (H01) to the “B ports” on the NORAC valve block.
5. Disconnect the pressure and tank hoses from the sprayer valve block and insert the 6FJXR-
6MJT tees (F04). If needed, use the 8FJXR-8MJT tee (F07) for the tank port.
6. Connect two hoses (H01) to the free end of the tees (F04) that were just installed. If the
8FJXR-8MJT tee (F07) was previously installed then use H02 instead of H01 for the tank
line.
7. Connect the other end of the hoses (H01) to the pressure and tank ports on the NORAC
valve block.
