NORAC UC4.5-BC-SM2 User Manual
Page 23
20
Figure 20: Hoses Connected to NORAC Valve
Block
Figure 21: Raise and Lower Line Connections
Figure 22: Tank and Pressure Connections
NORAC
Pressure
Line (H03)
NORAC
Tank Line
(H03)
SpraCoupe
Pressure
Port
F04
SpraCoupe
Pressure
Tee
F04
“Lower”
Lines (H02)
Tank Line
(H03)
Pressure
Line (H03)
“Raise”
Lines (H02)
H02
Existing
Steel
Lines
Existing
Hoses
F02
