NORAC UC4.5-BC-HD9 User Manual
Page 16
13
18. Connect two cables (C05) to the 8-way coupler and route along the booms to the wing
sensors. Follow existing cables and hoses to be sure the cable will not be pinched or
stretched.
19. At the sensor brackets, attach a 2-way coupler with terminator (E20) to the sprayer boom.
The 2-way coupler with terminator is the white two way coupler. Plug the sensor and the
CANbus cable into the 2-way coupler.
20. Insert the 6-pin plugs (P03) into the unused connectors on the 8-way coupler (E11).
IMPORTANT:
Provide enough slack in all cables to account for all boom movement and
FOLDING boom movement.
