Mytek Stereo 192 Sample Rate Converter – User Manual
•
P. up
◦
44144 Hz
◦
45937 Hz
◦
48048 Hz
◦
50000 Hz
Once the desired frequency is selected push SEL to confirm.
Custom Value – hold down SEL until the first digit starts
flashing. Press UP to set the desired digit value. Press SEL to
confirm the value and move on to the next digit. After the
most significant digit is set the unit is now ready for
operation.
The minimum frequency that can be set is 32000 Hz. The
maximum is 192000 Hz.
Upon selection of the frequency the display will adjust to the
selected value once the PLL is locked to the frequency.
For user defined
frequencies less than
100,000 the left most digit
will be blank but it is still
cycled through with the
“SEL” button. The value
set won't be confirmed
until you push the “SEL”
button after the last digit.
