Fuses
Usage
RVC
Regulated Voltage Control
IPC/DIC
Instrument Panel
Cluster/Driver Information
Center
HVAC/ECAS
Climate Control Controller
CIG LTR
Cigarette Lighter
HI HDLP-RT
Passenger’s Side High Beam
Headlamp
HDLP-LOW
Headlamp Low Beam Relay
A/C COMP
Air Conditioning Compressor
Relay
A/C COMP
Air Conditioning Compressor
TCMB
Transmission Control Module
RR WPR
Not Used
RADIO
Audio System
SEO B1
Mid Bussed Electrical Center,
Universal Home Remote
System, Rear Heated Seats
LO HDLP-LT
Driver’s Side Headlamp
Low Beam
Fuses
Usage
BTSI
Brake Transmission Shift
Interlock System
CRNK
Starting System
LO HDLP-RT
Passenger’s Side Headlamp
Low Beam
FOG LP
Fog Lamp Relay
FOG LP
Fog Lamps
HORN
Horn Relay
W/S WASH
Not Used
W/S WASH
Not Used
INFO
OnStar
®
/Rear Seat
Entertainment
RADIO AMP
Radio Amplifier
RH HID
Right Hand High Intensity
Discharge Lamp
HORN
Horn Fuse
EAP
Electric Adjustable Pedals
TREC
All-Wheel Drive Module
(If Equipped)
SBA
Supplemental Brake Assist
5-117
