Fuses
Usage
PARK LP
Parking Lamps Relay
STRTR
Starter Relay
INTPARK
Interior Lamps
STOP LP
Stoplamps
TBC BATT
Truck Body Controller
Battery Feed
SEO B2
Off-Road Lamps
4WS
Not Used
AUX PWR
Accessory Power
Outlet — Console
PCM 1
Powertrain Control Module
ETC/ECM
Electronic Throttle Control,
Electronic Brake Controller
IGN E
Instrument Panel Cluster,
Air Conditioning Relay,
Turn Signal/Hazard Switch,
Starter Relay
RTD
Electronic Suspension
Control, Automatic Level
Control (ALC) Exhaust
TRL B/U
Backup Lamps Trailer Wiring
Fuses
Usage
F/PMP
Fuel Pump (Relay)
B/U LP
Back-up Lamps, Automatic
Transmission Shift Lock
Control System
RR DEFOG
Rear Window Defogger
HDLP-HI
Headlamp High Beam Relay
PRIME
Not Used
AIRBAG
Supplemental Inflatable
Restraint System
FRT PARK
Front Parking Lamps,
Sidemarker Lamps
DRL
Daytime Running Lamps
Relay
SEO IGN
Rear Defog Relay
TBC IGN1
Truck Body Controller Ignition
HI HDLP-LT
Driver’s Side High Beam
Headlamp
LH HID
Left Hand High Intensity
Discharge Lamps
DRL
Daytime Running Lamps
5-116
