Desktop Board Features
13
Table 2. Intel Desktop Board D945GSEJT Components
Label Description
A
Back panel connectors
B 12 V processor core voltage connector (2 x 2)
C SO-DIMM Connector
D Intel 82945GSE GMCH
E Intel Atom processor N270
F Serial port (COM 2)
G Serial port (COM 1)
H PS/2 keyboard port header
I Reserved
J
PATA connector (44 pin)
K Reserved
L Chassis
fan header
M Chassis intrusion header
N SATA 0 connector
O SATA power connector
P SATA 1 connector
Q Intel 82801GBM I/O Controller Hub (ICH7-M)
R Parallel port header
S Reserved
T Reserved
U
Front panel header
V Front panel wireless activity LED header
W PCI Express Mini Card connector
X BIOS configuration jumper block
Y PCI bus connector
Z S/PDIF header
AA Front panel USB header
BB Internal mono speaker header
CC Front panel audio header
DD Front panel USB header with Intel Z-U130 USB Solid-State Drive (or
compatible device) support
