Checking Fuses
The Schwintek In-Wall™ Slide requires a minimum of 30 amp fuse. Check the 12 volt fuse box for
blown fuses, and replace any if necessary. Consult the rv manufacturers documentation for the
location of the 12 volt fuse box, and the location of the Room Slide Controller’s fuse. If the fuse blows
immediately upon replacement, there is a problem with the wiring to the In-Wall™ Slide control box.
Have qualified service personnel check and repair.
Obstructions
Check outside the rv for possible obstructions: tree, post, car, etc… Check inside the rv for any
obstructions: luggage, furniture, open cabinets, etc… Also check for smaller objects that may be
wedged under the floor or in the sides of unit. Remove obstructions before proceeding.
Error Codes
Consult rv manufacturer’s documentation for the location of the In-Wall™ Slide Controller. See page 1
for a description of the error codes, and possible problems.
Low Voltage
The Schwintek In-Wall™ Slide Controller is capable of operating the room with as little as 8 volts.
But at these lower voltages the amperage requirement is greater. Check voltage at the controller. If
voltage is lower than 11 volts, it is recommended that the battery be placed on a charger until it is
fully charged. It may be possible to ’jump’ the rv’s battery temporarily to extend or retract the room.
Consult the rv manufacturer’s owners manual on the procedure for ‘jumping’ or charging the battery.
**********Never ‘jump’ or charge the battery from the power connections on the In-Wall™
Controller. Always do this at the battery.*****************
Only 1 side moving
The Schwintek In-Wall™ Room Slide has a separate moto
r
to operate each side of the room. Does
only 1 side of the room move a short distance (2 to 4 inches) and stop.
Will non moving side move with help?
If only 1 side of the room is moving, then with someone’s assistance press the switch to extend or
retract the room while pushing the non moving side in the appropriate direction. On larger rooms it
may be necessary to have 2 or more people pushing the room.
Non moving side moved manually
Try to push the non moving side in and out. If a motor shaft has broken then it will be possible to
move that side of the room several inches by hand. Larger rooms may require several people to push.
Debris in the rack
Check all 4 gear racks on the side of the room for debris.
Do status led’s light
Consult the rv manufacturers documentation for the location of the Room Slide Controller. When the
room slide direction switch is actuated, do the status led’s light up. Check this in both the extend and
retract modes.
IF YOU HAVE ANY PROBLEMS OR QUESTIONS; CONSULT
YOUR LOCAL AUTHORIZED DEALER OR CONTACT LIPPERT
PHONE: (866) 524-7821 - E-MAIL: [email protected]
